Finch Module
building
Multifunctional CLT module
A Finch unit was cut in half for the purpose of daylighting.
After placing the Finch modules.
Lifting Finch Module on the GTB Lab deck.
The steel profiles on the bottom of the module are placed on the intermediate timber structure.
Previous life of Finch unit as a home in the East of Netherlands.
Summary
Finch units are cross-laminated timber (CLT) units produced by De Groot Vroomshoop.
Details
The unit has been used as a home and reused as a demonstration space in the GTB Lab. The unit has been sawn in half to create a light space in the centre. Daylight is an important indicator of the transformability of buildings. Unlike reinforced concrete, CLT is relatively easy to cut. After reconnecting the installations of both halves, it functions as a demonstration space.
Owner
Architect
Industry consortium
De Groot Vroomshoop, Aveco de bondt, Nieman Groep, Loohuis installlatiegroep, Rockstart, De Mors
Location
De Groot Vroomshoop Groep B.V., Zwolsekanaal, Vroomshoop, Nederland
Construction year
2014
Gross floor area
30,11 m2
Gross building volume
111,32 m3
Hazardous materials
None
Circularity data
Embodied mass:
Embodied carbon:
15,36 ton
34,63 ton CO2
Circularity Profile:
direct reuse/reuse by repair:
recycling:
waste:
Reused mass:
Reused carbon:
9,7 ton
23,7 ton
No. of elements:
No. of disassembly steps:
80
10
Circularity profile
Ratio of Reuse Potential after processing.
Tonnage
Carbon
Material per recovery option
Ratio of Reuse Potential.
Tonnage
Carbon
Reused materials per function, and per recovery option
Tonnage
Carbon
Breakdown of materials
Tonnage
Carbon
Overview of materials per recovery option
Tonnage
Carbon
