Timber Roof

element

Reversible timber roof

Timber Roof
0.8

Main beam before lifting it to its place.

Sliding beam over steel intermediairs.

Detail of connections.

Summary

The roof of the GTB Lab is the physical and architectural umbrella under which the experiments take place. It protects the activities and provides horizontal structural stability that allows for different kinds of transformations.

Details

The roof of the GTB Lab demonstrates how reversible core parts of a building allow for different transformations. The size provides flexibility for many unknown future developments.

The roof is made of laminated timber beams connected by steel joints. The diagonal pattern provides structural stability. The secondary beams are srewed on the main beams. The main beams and eaves are connected by steel plates and bolts for easy disassembly.

All elements were prefabricated and transported to site. The time on site was limited to a few days. The connection to the building also took place via intermediary steel joints between roof and tree columns/core steel frame.

Design

4D Architects

Manufacturer

De Groot Vroomshoop

Manufacturing location

De Groot Vroomshoop Groep B.V., Zwolsekanaal, Vroomshoop, Nederland

Materials

Dimensions

Length:

Width:

Height (or depth):

Thickness:

37 680 mm

11 280 mm

760 mm

Shape

Surface damage

Hazardous materials

None

Material history

2021 - produced in Enschede NL and placed at GTB Lab

Circularity data

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
RP Product legend.png

Embodied mass:

Embodied carbon:

19,35 ton

24,91 ton CO2

Reuse Potential:

Recovery option

0.8

Reuse by minor repair

Reused tonnage:

Reused carbon:

No. of elements:

No. of disassembly steps:

240

Remaining Technical Life Cycle:

97 year
