Jansen VISS Facade
element
Steel facade system
Intermediary connector.
Jansen VISS Linea mullion connected to Skellet with intermediary.
Summary
The Jansen VISS facade system, based on intermediaries and interlock connection, allows different subsystems to be assembled and disassembled independently by locking one element to two connecting parts.
Details
An intermediary connects the steel profiles to the load-bearing system, based on interlocking. Facade elements such as glazing are clamped to the mullion/transom structure using pins and clamping profiles. An aluminium cover profile is clicked on from the outside for finishing.
Design
4D Architects
Manufacturer
Jansen AG
Manufacturing location
Industriestrasse 34, Oberriet, Zwitserland
Materials
Dimensions
Length:
Width:
Height (or depth):
Thickness:
2x 4 900 mm
152 mm
3 125 mm
Shape
Surface damage
Hazardous materials
None
Material history
2019 - produced by Jansen and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circularity data
Embodied mass:
Embodied carbon:
1,91 ton (62,4 kg/m2)
4,00 ton CO2 (130,4 kg CO2/m2)
Reuse Potential:
Recovery option
0.7
Reuse by minor repair
Reused tonnage:
Reused carbon:
1,34 ton (43,7 kg/m2)
2,80 ton CO2 (91,3 kg CO2/m2)
No. of elements:
No. of disassembly steps:
62
Remaining Technical Life Cycle:
95 year
