GTB Lab Module

element

Multifunctional reversible module

GTB Lab Module
0.8

3 transformations of GTB Lab without waste. The façade with door transforms into a terraced module, which in GTB Lab transforms into a light intermediate module.

Test of transformations: floor becomes roof, which becomes facade, which becomes terrace and again becomes facade with door, etc.

Summary

GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts.

Details

GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts. ","4 reversibility scenarios have been investigated and applied.
1. Reversibility at module level, including replicability of façade, roof, floor, e.g. using the façade cassettes to create a floor/terrace that has taken place during the modules, and extensibility of the module transformation.
2. Reversibility at component level, including reconfiguration of the floor, roof or facade cassette by transforming the door into a window or shelf.
3. Coordination of design and production dimensions to eliminate 98% of production waste.
4. 3D module replicability/transportation and module expandability.

Design

4D Architects

Manufacturer

Kloeckner Metals ODS NL

Manufacturing location

Keurmeesterstraat 4, 2984 BA Ridderkerk

Materials

Dimensions

Length:

Width:

Height (or depth):

Thickness:

4 800 mm

4 800 mm

3 625 mm

Shape

Surface damage

Hazardous materials

None

Material history

2019 - produced and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL

Circularity data

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
RP Product legend.png

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.

Embodied mass:

Embodied carbon:

14,34 ton

23,92 ton CO2

Reuse Potential:

Recovery option

0.8

Reuse by minor repair

Reused tonnage:

Reused carbon:

9,8 ton

16,5 ton CO2

No. of elements:

No. of disassembly steps:

353

10

Remaining Technical Life Cycle:

95 year
