Pilkington Sunplus™ BIPV

component/systeem

Reversible power generating glass

Pilkington Sunplus™ BIPV
0.8

Connection points for the electric cables to the invertor.

Solar strips allow filtered sunlight to enter the building.

Samenvatting

Solar windows made of power generating insulating glass elements based on photovoltaic strips inside the triple glazing.

Details

Energy producing glazing is a solution for making homes and other buildings energy efficient. The strips generate energy, filter direct sunlight (reduce heat stress) and the triple glazing is the highest quality insulation. In addition it is an integrated part of the architecture and building façade.

Waste during production was minimised by using the maximum production width of the glass (1180mm) as the grid size for the GTB Lab Module. In the subsequent transformation phase, no new material was used at all, but the glass was reused in its entirety.

Ontwerp

Pilkington

Producent

Pilkington Nederland BV

Productielocatie

De Hoeveler 25, Enschede, The Netherlands

Industrieconsortium

Afmetingen

Lengte:

Breedte:

Hoogte (diepte):

Dikte:

Oppervlak:

Volume:

3 100 mm

1 180 mm

52 mm

Schadelijke stoffen

Geen

Geschiedenis

2019 - produced by Pilkington and assembled in Ridderkerk NL
2021 - reused in GTB Lab, Heerlen NL

Circulariteitsgegevens

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
RP Product legend.png

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.

Gewicht:

Opgenomen CO2:

207,25 kg (56,7 kg/m2)

362,07 kg CO2 (94,6 kg CO2/m2)

Hergebruikpotentieel:

Terugwinningsopties:

0.8

Reuse by minor repair

Hergebruikt gewicht:

Hergebruikte CO2:

165,80 kg

289,66 kg CO2

Aantal elementen:

Aantal demontagestappen:

1

Resterende Technische Levenscyclus:

24 jaar

gtb lab phase 1 - circularity profile tonnage.jpg

gtb lab phase 1 - circularity profile tonnage.jpg

gtb lab phase 1 - tonnage recovery option.jpg
gtb lab phase 1 - carbon recovery option.jpg
gtb lab phase 1 - tonnage avoided waste.jpg
gtb lab phase 1 - carbon avoided waste.jpg
gtb lab phase 1 - tonnage material distr.jpg
gtb lab phase 1 - carbon material distr.jpg
gtb lab phase 1 - tonnage overview materials.jpg
gtb lab phase 1 - carbon overview materials.jpg
