Rodeca Facade

element

Modular translucent facade system

Rodeca Facade
0.7

Intermediar aluminium profile connecting the polycarbonate panels to each other and to the load bearing frame.

Section view off the taped tongue-and-groove panels.

The narrow horizontal façade sections can be removed and provide flexibility to allow structural connections to the steel structure behind.

Samenvatting

The Rodeca polycarbonate facade system is reversible, flexible, light weight, highly insulating, strong, weather resistant and translucent.

Details

Rodeca installed its polycarbonate panels on the GTB Lab. First the main roof, then the core and finally the circular GTB module. The material has the same insulation value as triple glazing and allows daylight into the building, but also has some advantageous reversible properties. It is not as fragile as glass and more than 10 times lighter. More importantly, the elements can be assembled and disassembled quickly, easily and with a minimum of waste. The reversible GTB Lab module shows that the CO2 emissions per m2 of facade are 2.5 times lower for the polycarbonate panel than for glass, not to mention the CO2 emissions avoided due to the lighter supporting structure.

Ontwerp

Rodeca

Producent

Rodeca Gmbh

Productielocatie

Freiherr-vom-Stein-Straße 165, Mülheim an der Ruhr, Germany

Materialen

Afmetingen

Length:

Width:

Height (or depth):

Thickness:

12 390 mm

15 000 mm

150 mm

Vorm

Oppervlakteschade

Schadelijke stoffen

Geen

Materiaalgeschiedenis

2021 - produced by Rodeca and assembled in GTB Lab, Heerlen NL

Circulariteitsgegevens

Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
RP Product legend.png

Gewicht:

Opgenomen CO2:

3,90 ton (22,52 kg/m2)

9,07 ton CO2 (52,47 kg CO2/m2)

Hergebruikpotentieel:

Terugwinningsopties:

0.7

Reuse by minor repair

Hergebruikt gewicht:

Hergebruikt CO2:

2,73 ton (15,76 kg/m2)

6,35 ton CO2 (36,72 kg CO2/m2)

Aantal elementen:

Aantal demontagestappen:

394

Resterende technische levenscyclus:

69 jaar
