Reversible Wooden Cassette

element

Modular LVL timber system

Reversible Wooden Cassette
0.9

Wooden Cassette as facade.

Left: reassembled on-site at GTB Lab.
Right: after finishing.

Test of transformations: floor becomes roof, which becomes facade, which becomes terrace and again becomes facade with door, etc.

Assembly & disassembly zoom in

On-site assembly of reversible wooden cassette as floor at GTB Lab

Samenvatting

The Reversible Wooden Cassette has been developed within the EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential.

Details

Reversible Wooden Cassette is a LVL-based modular timber system with full reversibility in mind. LVL (Laminated Veneer Lumber) allows the construction of standardised reversible wooden cassettes which can be applied as floor, roof or facade components. Using prefabricated geometry and universal connections the reversible wooden envelope can serve as floor, roof, or ground slab. Locking half blind Dado joints allow the modularity of the wooden structure. Steel intermediary connections are fixing the wood on the load bearing base system of the GTB Lab Module.
Reversible Wooden Cassette is initiated by GTB Lab and first tested and used in the GTB Lab Module during the EU BAMB project.

Ontwerp

4D Architects

Producent

TheNewMakers

Productielocatie

Benedenrijweg 186, Ridderkerk, The Netherlands

Materialen

Afmetingen

Length:

Width:

Height (or depth):

Thickness:

3 025 mm

2 300 mm

165 mm

Vorm

Oppervlakteschade

Schadelijke stoffen

Geen

Materiaalgeschiedenis

2019 - produced and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL

Circulariteitsgegevens

Omkeerbaar/Reversible BIM: het 3D-model met kleurcodering visualiseert per element het hergebruikpotentieel.
RP Product legend.png

Omkeerbaar/Reversible BIM: het 3D-model met kleurcodering visualiseert per element het hergebruikpotentieel.

Gewicht:

Opgenomen CO2:

72 kg

87 kg CO2

Hergebruikpotentieel:

Terugwinningsopties:

0.9

Direct hergebruik

Hergebruikt gewicht:

Hergebruikt CO2:

53 kg

64 kg CO2

Aantal elementen:

Aantal demontagestappen:

10

6

Resterende technische levenscyclus:

70 jaar
