GTB Lab Module
element
Multifunctional reversible module
3 transformations of GTB Lab without waste. The façade with door transforms into a terraced module, which in GTB Lab transforms into a light intermediate module.
Test of transformations: floor becomes roof, which becomes facade, which becomes terrace and again becomes facade with door, etc.
Samenvatting
GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts.
Details
GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts. ","4 reversibility scenarios have been investigated and applied.
1. Reversibility at module level, including replicability of façade, roof, floor, e.g. using the façade cassettes to create a floor/terrace that has taken place during the modules, and extensibility of the module transformation.
2. Reversibility at component level, including reconfiguration of the floor, roof or facade cassette by transforming the door into a window or shelf.
3. Coordination of design and production dimensions to eliminate 98% of production waste.
4. 3D module replicability/transportation and module expandability.
Ontwerp
4D Architects
Producent
Kloeckner Metals ODS NL
Productielocatie
Keurmeesterstraat 4, 2984 BA Ridderkerk
Materialen
Afmetingen
Length:
Width:
Height (or depth):
Thickness:
4 800 mm
4 800 mm
3 625 mm
Vorm
Oppervlakteschade
Schadelijke stoffen
Geen
Materiaalgeschiedenis
2019 - produced and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
Gewicht:
Opgenomen CO2:
14,34 ton
23,92 ton CO2
Hergebruikpotentieel:
Terugwinningsopties:
0.8
Reuse by minor repair
Hergebruikt gewicht:
Hergebruikt CO2:
9,8 ton
16,5 ton CO2
Aantal elementen:
Aantal demontagestappen:
353
10
Resterende technische levenscyclus:
95 jaar
